LED Mini Wall Washer Outdoor Lights SMD China 10w For Building Projecting

Light projecting Building facade design idea for outdoor LED high power wall washer lights

Lamp Item No.: LE-XQNT15-48/60

LED RGB wall washer outdoor 10w are efficient, Apply to building facade, sculptures and locations which require emphatic lighting energy saving replacements for metal halide and quartz halogen fixtures,containing an integral listed driver.
The fixtures can mount at a broad range of angles with ayoke style arm.

New heat releasing structure, a unique heat releasing technology. 1-2 times larger cooling area than the traditional square floodlight.

Revolving bracket， it is convenient to adjust the projecting angles. Can be customed made the bracket according to your requirement.

Use Cree/Osram LED chip, with the professional optical lens, good quality, uniform color, higher brightness.

High strength AD12 dia-casting aluminum housing, tempered glasses. Akzo Nobel powder coating surface, outdoor grade, anti-UV.

High standard aging test. Waterproof requirements are all 0.5M deep water test for 8 hours. IP grade all are above IP65.

A variety of color temperature choose (1700K-6500K).

Product FAQ

Samples within 7 working days, mass production time needs 2-3 weeks for order quantity more than.

Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.

we also offer customized service.if you have any question,please feel free to contact us.

Provide to your needs and customized to suit different customers, Including color, size, material, etc. According to your design and manufacture of molds.

LED rgb wall washer outdoor lights apply to outdoor facade illumination, sculptures and locations which require emphatic lighting energy saving replacements for metal halide and quartz halogen fixtures,containing an integral listed driver.
Material: Aluminum alloy housing, tempered glass, stainless steel screw, Akzo Nobel powder coating, outdoor grade, anti-UV.
Effects: RGB color-changing, flowing, chasing, 256 grades brightness.

LELED Lighting is a excellent manufacturer of Outdoor RGB Wall Washer products in China.
We only provide high quality outdoor LED light with reasonable price, Factory direct sales with competitive price.
Complete & strict quality control system from incoming material quality control, All outdoor wall washer must accept accept 5 kinds of checks during production, raw material check, Lights beads check, Aluminum plate check, Power supply check and the finished products need to pass 48 hours aging test.

Product Data
More Information

Weight	1 kg	Dimensions	1000 × 15 × 36 cm
Lighting projection effect	Floodlights, Projector, Wallwashers	Light distribution	Flood, Narrow spot, Wallwash
Input voltage (V)	DC24V(RGB), DC24V(Single color)	LED lights power (W)	12W, 15W
Number of LED	48pcs, 60pcs	Power factor	0.98
Protection class (IEC)	III (Safety class III)	Working temperature (°C)	-30 °C ~ +45°C
Light material	Aluminum alloy housing	Average life	50000 Hours
Beam angle (∠)	25,40,60	Cable	Cable 0.15m of plug, Cable 0.5 m without plug
Color rendering index (CRI)	Ra>85	Installation method	Surface mounted
LED light IP rating	IP66	LED light source	CREE SMD LED, Epistar SMD LED
Control method	DMX512	Certification	CE mark, Rohs mark

RGB wall washer lighting default size: 1000mm X 36mm X 15mm

FEATURES OF PRODUCT

leled lighting led linear length size for leled lighting

Customized led lights lengths

Customized led lights of different lengths according to the project

High standard light distribution, good light effect

Choose high-quality PMMA lens and imported LED, Lens with good light efficiency is preferred.

Long Lasting Quality

All aluminum lamp housing, Good thermal conductivity, Light attenuation is small.

IMAGE GALLERY

Light projecting bridge facade design idea for outdoor LED high power wall washer lights
